Description

Range Acti 9
Series iC60H
Current Rating 20A
Trip Sensitivity 30mA
Number of Poles 1P+N
Mounting Style DIN Rail Mount
Rated AC Voltage 240 V ac
Circuit Breaker Type RCBO
Tripping Characteristics Type B
Breaking Capacity at Maximum Voltage Rating 1000 A 240 V
Terminal Contact Type Screw
Tripping Mechanism Thermal-MagneticProtection against short-circuits and cable overloads

Protection of persons against electric shock by direct contact (10, 30 mA sensitivities)

Protection of persons against electric shock by indirect contact (100 mA sensitivity)

Protection of equipment against fires set by leakage currents (100 mA sensitivity)
