Description

Range Acti 9
Series iC60H
Current Rating 45A
Trip Sensitivity 30mA
Number of Poles 1P+N
Mounting Style DIN Rail Mount
Tripping Characteristics Type A
Circuit Breaker Type RCBO
Tripping Mechanism Thermal-Magnetic
Breaking Capacity at Maximum Voltage Rating 1000 A to 240 V
Terminal Contact Type ScrewProtection against short-circuits and cable overloads

Protection of persons against electric shock by direct contact (10, 30 mA sensitivities)

Protection of persons against electric shock by indirect contact (100 mA sensitivity)

Protection of equipment against fires set by leakage currents (100 mA sensitivity)
