Description

Wago 222-412 32 Amp lever terminal block connector 4mm. Supplied as a pack of 50. Wago connectors are designed for ease of use, ideal for saving electricians time and money. Suitable for the connection of 2 terminals.

Wago 222 connectors benefit from simple, effective design. The compact housing is ideal for maximising wiring space throughout restricted environments such as a junction box and are ideal for usage throughout a wide range domestic and industrial applications.

Utilising a simple lever clamp system provides fast, easy and secure termination whilst requiring no tools for completion. Wago 222-412 supports the connection of solid, stranded and fine stranded cables. The sturdy lever clamp effectively protects the conductor from accidental damage or coming loose, fantastic for free wiring. When the cable is stripped to the correct length of 9-10mm the connection is completely protected from accidental contact with the live element. A handy length indicator is provided on the terminal block housing, detailing the correct length the wire should be stripped.

A test slot is provided for easy testing access with standard test probes.

Wago 222 connectors are ideal for usage with Wagobox 51009319.

Features of Wago 222-412:
2- Way terminal block
Supplied as a pack of 50
Requires cable stripped to a length of 9-10mm
Reusable
2-conductor connector with operating levers
Easy termination via reduced operating force
Solid conductor size: 0.08mm²-2.5mm²
Stranded conductor size: 0.08mm²-2.5mm²
Fine stranded conductor size: 0.08mm²-4mm²
Test slot for all standard test probes
Max current: 32A
Max voltage: 400V
Height: 14.5mm
Width: 12.4mm
Depth: 20.5mm
Compliant with EN 60664
